PROVISION CRANES

Masada’s provision cranes are designed to offer unparalleled versatility, with a design that is not only highly adaptable but also customizable to precisely meet the unique specifications and needs of our customers.

STIFF BOOM CRANES

Ranges from 100 to 9000KNM.

Main Specifications and Parameters (Stiff Boom Cranes)

Type	SWL (t)	(m)	(m/min)	(r/min)	(kW)	(kN.m)	(kN)	Length (mm)	Width (mm)	Height (mm)	Diameter (mm)	Crane Weight (KG)
1T x 10M	1	10	12	0.5	15	226	47	10350	2000	4100	700	3100
1T x 12M	1	12	10	0.5	15	241	49	13000	2000	4200	1000	3500
1.5T x 6M	1.5	6	15	0.5	11	223	43	6300	1300	4000	700	3100
2T x 4M	2	4	18	0.5	15	310	55	5000	1500	3800	920	2700
2T x 8.1M	2	8.1	10	0.5	15	300	70	9000	2600	4500	1080	4100
2T x 10M	2	10	12	0.5	22	470	60	11500	2400	4700	1000	4350
2T x 12.5M	2	12.5	10	0.6	22	513	64	13500	2500	5100	1000	5080
2T x 15.5M	2	15.5	10	0.6	22	520	65	15500	2500	5100	1000	5980
3T x 6M	3	6	10	0.6	22	350	64	7100	2000	4950	1000	4800
3T x 7M	3	7	10	0.6	22	380	75	8100	2000	4950	1080	5100
3T x 8M	3	8	15	0.5	22	410	81	9200	2100	4900	970	5100
3T x 14M	3	14	12	0.5	22	620	91	15400	2500	5100	1400	6500
3.5T x 12M	3.5	12	10	1	30	620	90	13000	2500	5100	1250	6500
4T x 8.1M	4	8.1	10	0.5	22	450	85	9200	2200	4900	1080	5200
4T X 15.5M	4	15.5	10	0.6	30	1500	183	17000	3000	5100	1400	9400
4T x 7M	4	7	12	0.5	22	630	91	8100	2100	4900	1250	5100
4T x 13M	4	13	10	1	30	1300	150	14000	2200	4900	1250	5600
5T x 16M	5	16	10	0.5	30	1500	150	1700	3200	5700	1400	11000
6.5T x 13M	6.5	13	10	0.5	30	1500	180	15000	3200	6100	1400	10650
10T x 16M	12	16	10	0.6	75	2500	415	18000	3300	7100	2000	21000
10T x 18M	10	18	10	0.6	60	2300	250	20000	3300	6200	1600	14500
10T x 19M	10	19	10	0.6	60	2600	280	21000	3300	6200	1600	15200
10T x 19M	10	21	10	0.6	75	3900	440	23000	3000	7100	2000	22000
10T x 22.5M	10	22.5	10	0.6	75	3400	415	24000	3300	7100	2000	24000
10T x 25M	10	25	10	0.6	75	4100	470	27000	3000	7100	2200	23000
12.5T x 2M	12.5	22	12	0.6	75	4800	510	24000	3200	6500	2100	22345
15T x 19M	15	19	10/20	1	90	4900	560	21000	3300	6500	2200	22000
15T x 20M	15	20	10/20	1	90	4900	560	21000	3300	6500	2200	23000
15T x 22.5M	15	22.5	12	0.8	90	5200	530	24000	3300	7000	2300	32000
15T x 25M	15	25	10	0.8	90	6100	620	27000	3300	7000	2600	36000
25T x 21.2M	25	21.2	20	1	105	8000	780	25000	5000	9100	2600	52000
30T x 8.8M & 15T x 14M	30/20/15	8.8/10.8/14	10	0.6	105	6000	750	18000	5000	6500	2500	43000

HOSE HANDLING CRANES

XXX

Main Specifications and Parameters (Hose Handling Crane)

Type	SWL (t)	(m)	(m/min)	(r/min)	(kW)	(kN.m)	(kN)	Length (mm)	Width (mm)	Height (mm)	Diameter (mm)	Kg
5T x 18M	5	18	15/30	0.5	37	1700	190	18000	2600	4800	1420	12000
10T x 16M	10	16	10	0.6	75	2500	415	16000	3300	7100	2000	21000
10T x 22.4M	10	22.4	10/20	0.5	–	–	–	24000	3800	4800	2000	20000
10T x 25M	10	25	10	0.6	75	4100	470	27000	3000	7100	2200	23000
15T x 19M	15	19	10/20	1	90	4900	560	21000	3300	6500	2200	22000
15T x 20M	15	20	10/20	1	90	4900	560	21000	3300	6500	2200	23000
15T x 22.5M	15	22.5	12	0.8	90	5200	530	24000	3300	7000	2300	32000
15T x 23.4M	15	23.4	10/20	0.5	–	–	–	25000	3800	5200	2110	30500
15T x 25M	15	25	10/20	0.7	90	6100	620	27000	3300	7000	2600	36000
15T x 26.5M	15	26.5	10/20	0.5	–	–	–	28000	3100	5300	2110	32500
20T x 18.6M	20	18.6	10/20	0.5	–	–	–	19600	3100	5100	2100	23500
20T x 20M	20	20	10/20	0.5	–	–	–	22000	4000	8300	–	25000
20T x 20M	20	20	10/20	0.5	–	–	–	22000	4000	5500	–	–

ELECTRIC DRIVEN WIRE LUFFING CRANE

Ranges from 80 to 1200KNM

Main Specifications and Parameters (Electric Driven Wire Luffing Crane)

Type	SWL (t)	(m)	(m/min)	(s)	(r/min)	(kW)	(kN.m)	(kN)	Length (mm)	Width (mm)	Height (mm)	Diameter (mm)	Kg
2T x 4M	2	4	10	60	0.5	6.3/6.3/2.5	201	83	4500	2100	4200	810	3419
3T x 8M	3	8	10	/	0.5	8.5/8.5/4	350	32	9700	2300	5800	1000	5700
5T x 11.8M	5	11.8	10	90	0.8	18.5/18.8/7.5	480	61	13900	2300	6500	1250	8100
4T x 21.5M & 8T x 15M	4	21.5	11	120	0.6	22/22/13	1700	210	25000	3600	12500	1500	12600
5.5T x 21.5M & 8T x 15M	5.5	21.5	1	120	0.6	22/22/13	1700	210	25000	3600	12500	1500	12600

MONORAIL CRANE

Ranges from 4T up to 12.5T

Main Specifications and Parameters (Monorail Crane)

Type	SWL (t)	(m)	(m/min)	(r/min)	(kW)	(kN.m)	(kN)	Length (mm)	Width (mm)	Height (mm)	Diameter (mm)	Kg
4T	4	4	10	/	13/13/4	/	/	28400	1700	2000	/	5700
5T	5	4	10	/	15/15/4	/	/	28400	1800	2000	/	7296
8T	8	22	10	11	22/22/8.5	/	/	46000	2200	2865	/	22000
12.5T	12.5	4	10	10	30/30/15	/	/	48000	2000	3500	/	32967

KNUCLE BOOM CRANE

Ranges from 180 to 4500KNM

Knuckle Boom Crane Specifications

Type	SWL (t)	(m)	(m/min)	(s)	(r/min)	(kW)	(kN.m)	(kN)	Length (mm)	Width (mm)	Height (mm)	Diameter (mm)	Kg
2T x 10M	2	10	12	90	0.7	30	470	60	11500	2000	3500	1000	3500
3T x 11M	3	11	12	90	0.7	30	570	71	11500	2000	3500	1250	4100
5T x 16M	5	16	15	90	0.6	37	1400	170	16000	1855	5800	1230	10000

Hydraulic Telescopic Boom Crane Specifications

Type	SWL (t)	(m)	(m/min)	(s)	(r/min)	(kW)	(kN.m)	(kN)	Length (mm)	Width (mm)	Height (mm)	Diameter (mm)	Kg
2.05T x 10M	2.05	10	15	15	1	30	470	60	11000	2000	4000	700	4500
5T x 10M	5	10	15	90	1.5	75	2000	220	22000	2500	6300	1600	25000

Hydraulic Telescopic & Knuckle Boom Crane Specifications

Type	SWL (t)	(m)	(m/min)	(s)	(r/min)	(kW)	(kN.m)	(kN)	Length (mm)	Width (mm)	Height (mm)	Diameter (mm)	Kg
1.5T x 12M & (3T x 6M)	1.5/3	6/12	12	90	0.7	30	570	71	13000	2000	3500	800	3670
2T x 9M	2	9	15	90	0.5	/	500	70	9000	1700	3400	650	5000

ENGINE ROOM CRANE

Ranges from 0.1T up to 12.5T

Manual Control Single Beam Engine Room Crane Specifications

Type	SWL (t)	(m)	(m/min)	Length (mm)	Width (mm)	Height (mm)	Kg
0.5T	0.5	/	4	7200	350	500	300
0.5T	0.5	/	8	7200	350	500	300
0.9T	0.9	/	8	7200	350	500	300
0.99T	0.99	/	8	7200	350	500	300
1T	1	/	8	7200	350	500	300

Electric Control Single/Double Beam Engine Room Crane Specifications

Type	SWL (t)	(m)	(m/min)	Length (mm)	Width (mm)	Height (mm)	Kg
2T x 8M	2	8	9.6/0.96	8500	2100	1500	2150
3T x 3.5M	3	3.5	9.6/0.96	4100	2100	1500	2150
4T x 6.8M	4	6.8	9.6/0.96	9500	2300	1600	3100
6.5T x 8.05M	6.5	8900	9.6/0.96	9500	2300	1600	3500
12.5T	12.5	9200	9.6/0.96	9200	3100	2500	8900

DAVITS CRANE

Ranges from 0.1T up to 2T

Air Davits Specifications (Davits Crane)

Type	SWL (t)	(m)	(m/min)	(kN.m)	(kN)	Length (mm)	Width (mm)	Height (mm)	Diameter (mm)	Kg
0.2T x 0.8M	0.2	0.8	10	/	/	1500	1000	2900	/	140
0.25T x 1.8M	0.25	1.8	10	/	/	1800	350	3900	/	170
0.5T x 1.8M	0.5	1.8	10	/	/	1800	450	3900	/	210
2T x 3M	2.5	3	5	75	41	3300	700	4100	450	3300

Manual Davits Specifications (Davits Crane)

Type	SWL (t)	(m)	(kN.m)	(kN)	Length (mm)	Width (mm)	Height (mm)	Diameter (mm)	Kg
0.2T x 2.8M	0.5	2.8	40	16	3100	450	3000	325	260
0.9T x 3M	0.9	3	43	17	3300	450	3000	325	280
0.9T x 3.6M	0.9	4.5	45	17	3800	450	3000	325	360
0.9T x 4.5M	0.9	2.8	75	45	4800	450	3000	325	360
